Benefits of OVC from BMA for optimal sugar crystallization

Design features:

The cooling system consists of standardized cooling block elements, in which water is forced to flow countercurrent to the massecuite. The entire cooling system oscillates vertically by 1 m. This, in conjunction with the symmetric arrangement of the cooling pipes, provides for optimized retention times and massecuite cooling. Two speeds are available for up/down movements of the cooling system. Six hydraulic cylinders, which are symmetrically mounted on the cover of the cooling crystalliser, drive the system. Half of the cooling blocks can be activated or deactivated at a time. With this type of crystalliser, the direction of massecuite flow is always from top to bottom. As it enters the unit, the massecuite is uniformly distributed across the entire crystalliser cross section by a slowly rotating distributor. There are no plain or anti-friction bearings, nor any glands, at the massecuite end throughout the entire crystalliser. The cooling water can be re-cooled in a separate cooling unit or in an air cooler, which is mounted on the lifting system and follows its oscillating movements. In this latter case, the complete secondary cooling water cycle is not required.

Efficient

Energy consumption no more than 15 kW
Energy consumption no more than 15 kW
ROI within the first two years 1)
ROI within the first two years
Optimised process technology
Optimised process technology
Maximum output Cooling surface of up to 1,400 m2
Maximum output Cooling surface of up to 1,400 m2
NEW: Throughput of up to 40 t/h in one cooling crystalliser
Throughput of up to 40 t/h in one cooling crystalliser
Maximum yield: cool down to 40° C
Maximum yield: cool down to 40° C

1) Calculation of the ROI is based on the length of an optimum campaign.

Consistent quality

Purity drop of up to 9 points
Purity drop of up to 9 points
Optimised desugarisation, no formation of fine crystals
Optimised desugarisation, no formation of fine crystals
Oscillating cooling surfaces for self-cleaning effect
Oscillating cooling surfaces for self-cleaning effect
Optimised retention times for high yields
Optimised retention times for high yields
3-step temperature control
3-step temperature control

Availability

Robust, low-maintenance hydraulic system
Robust, low-maintenance hydraulic system
Continuous operation
Continuous operation
For use in cane and beet sugar factories, refineries, and for non-sugar crystallisation
For use in cane and beet sugar factories, refineries, and for non-sugar crystallisation

Automation

“Essential” level included in basic scope of supply
“Essential” level included in basic scope of supply
Extensible with automation modules
Extensible with automation modules
